Detail| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001C |
| Color | Blue |
| MOQ | 1 Unit |
| Price | Negotiable |
| Payment Terms | T/T in Advance, Western Union, PayPal |
| Place of Origin | Shenzhen, China |
| Certification | CE / FCC / RoHS / ISO9001 |
Related Pages:
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001C |
| Color | Blue |
| Material | High-quality ABS plastic |
| Hull Size | 63.5 x 43.5 x 24 CM |
| Remote Distance | 500M |
| Sonar Frequency | 125 kHz |
| Sonar Range | 40M depth |
| Sailing Speed | 60 M/min |
| Battery Working Time | 3-4 Hours |
| Product Weight | 8 KG |
| Bait Hopper Capacity | 2 KG (Left + Right) |
| Waterproof Rating | IPX5 |
| Fish Finder Display | Remote control LCD display |
| Alarm | Audible alarm when fish detected |
| Certification | CE / FCC / RoHS / ISO9001 |
| MOQ | 1 Unit |
| Payment Terms | T/T, Western Union, PayPal |
| Place of Origin | Shenzhen, China |
Where the LYX-001C excels — from commercial carp lakes to remote reservoirs
Blue hull is easy to track at distance on open water — ideal for daylight scouting runs across large venues. Sail a 300–500M grid pass before setting up your swim. The sonar shows depth contours and bottom composition in real time. Spend 20 minutes mapping, then commit to the best-looking feature with confidence.
Deep gravel pits have complex topography invisible to conventional lead-dragging. The LYX-001C 125kHz sonar at 10–25M gives clean bottom echo on hard gravel. Locate underwater plateaux — these are major summer carp holding areas. Drop bait precisely on the plateau's edge rather than over it for maximum feeding area coverage.
In match fishing, swim choice decides the result. Run the LYX-001C along the available pegs before draw — note where fish arches appear on the sonar LCD. Combine this intelligence with wind direction and sun angle. Anglers who pre-scout with sonar consistently draw better-quality swims on commercial venues.
HK LIANYIXIN INDUSTRIAL CO., LIMITED is a professional manufacturer focused on miniature remote control fishing bait boats. With 10+ years of R&D and production experience, we provide stable, reliable and cost-effective products for global customers.
Our factory covers 8,000㎡ in Shenzhen, China, with a monthly capacity of 10,000+ units. All LYX series products are CE/FCC/RoHS/ISO9001 certified, exported to 50+ countries worldwide.
500M in open, flat-water conditions with no obstructions. On typical UK carp lakes (mostly under 10 acres), 500M exceeds the full width — you can scan the entire lake in one pass. On larger reservoirs, 500M covers the near bank to a clear midwater scouting run. Tree-lined banks reduce range to 380–420M due to signal absorption.
The sonar scans continuously at all speeds. For detailed underwater mapping, reduce speed to 30–40M/min — this gives each sonar ping more overlap with adjacent readings and produces cleaner LCD traces. At 60M/min (full speed), you still get depth readings and fish alarm function, but fine structure detail at 20M+ depth may be compressed. Use full speed for transit between swim areas, slow speed for detail scouting.
Yes. The 125kHz sonar transducer performs in both fresh and saltwater. Hull IPX5 rating handles sea splash and spray. After saltwater use, rinse motor housings, propeller shaft seals, and bait hopper hinges with fresh water immediately — salt crystallisation in moving parts causes accelerated wear. The battery compartment is adequately sealed for shore sea fishing conditions.
Sonar shows fish echo size and depth — not species. However, large carp (5KG+) produce a distinctly different echo signature from small silver fish: stronger echo, larger arch on the LCD display. Most experienced anglers learn to read the difference within a few sessions. The audible alarm can be sensitivity-tuned to trigger only on larger echoes, filtering bream and tench while flagging carp-sized signals.
Standard box: 1x Blue LYX-001C hull, 1x remote control, 1x lithium battery pack, 1x charger (EU/UK adapter included), 1x spare propeller set, 1x tool kit, 1x multilingual manual. Optional accessories: second battery pack (+$35), EVA carry case (+$25), boat hull cover (+$15). Contact aero@rc-fishingboat.com to add accessories to your order.
