Black GPS + Sonar Combo Bait Boat LYX-001D
Main
Angle 1
Angle 2
Feature
Scene
DetailHK LIANYIXIN Black GPS RC Bait Boat with Sonar Fish Finder Combo
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Black |
| MOQ | 1 Unit |
| Price | Negotiable |
| Payment Terms | T/T in Advance, Western Union, PayPal |
| Place of Origin | Shenzhen, China |
| Certification | CE / FCC / RoHS / ISO9001 |
Related Pages:
Technical Specifications
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Black |
| Material | High-quality ABS plastic |
| Hull Size | 63.5 x 43.5 x 24 CM |
| Remote Distance | 500M |
| GPS Accuracy | 3M |
| Sonar Frequency | 125 kHz |
| Sonar Depth Range | 40M |
| Sailing Speed | 60 M/min |
| Battery Working Time | 3-3.5 Hours |
| Product Weight | 8.5 KG |
| Bait Hopper Capacity | 2 KG (Left + Right) |
| Waterproof Rating | IPX5 |
| GPS + Sonar | Dual display LCD remote |
| Auto-Return | Yes (low battery + out of range + signal loss) |
| Certification | CE / FCC / RoHS / ISO9001 |
| MOQ | 1 Unit |
| Place of Origin | Shenzhen, China |
Key Features
- ✔Dual GPS + sonar technology in one compact hull
- ✔GPS waypoint navigation with 3M accuracy
- ✔125kHz sonar fish finder with 40M depth range
- ✔Audible fish alarm when carp detected
- ✔Low-profile black hull — minimal visual disturbance
- ✔Dual LCD display: GPS map + sonar reading simultaneously
- ✔Dual bait hopper (left + right), independently controlled
- ✔500M maximum remote control distance
- ✔Auto-return on low battery, signal loss, or manual trigger
- ✔IPX5 waterproof rating
- ✔OEM/ODM customization available
Application Scenarios
Where the LYX-001D excels — from commercial carp lakes to remote reservoirs
Pressured Day-Ticket Venues — Stealth Baiting
On venues where carp have been caught and released heavily, visual disturbance from a bait boat can spook fish for hours. The black hull on the LYX-001D provides the most discreet baiting option in our range while retaining full GPS+sonar intelligence.
Early Season Pre-Baiting Campaign
Early spring pre-baiting campaigns benefit from GPS precision — drop bait on the same spot consistently over 3–4 weeks to build a reliable feeding area. Sonar confirms the bottom composition matches a natural feeding zone.
Night Sessions on Estate Lakes
Estate lakes with overhanging trees are sonar+GSP territory: use sonar to navigate around submerged branches invisible from the bank, GPS to mark safe sailing routes, and deliver bait to productive spots in total darkness.
About HK LIANYIXIN
HK LIANYIXIN INDUSTRIAL CO., LIMITED is a professional manufacturer focused on miniature remote control fishing bait boats. With 10+ years of R&D and production experience, we provide stable, reliable and cost-effective products for global customers.
Our factory covers 8,000㎡ in Shenzhen, China, with a monthly capacity of 10,000+ units. All LYX series products are CE/FCC/RoHS/ISO9001 certified, exported to 50+ countries worldwide.
Frequently Asked Questions
Frequently Asked Questions
Q1: Is the black hull harder to see at distance during daytime?
Yes — this is intentional. Black hull blends with dark water at 80M+. If visual tracking is important for your fishing, the red or blue hull provides better daytime visibility. The black model's advantage is reduced visual disturbance to fish.
Q2: Does the stealth hull affect sonar performance?
No. Sonar transducer performance is identical across all hull colors. The black color is purely cosmetic — there is no performance difference between colors in any LYX model.
Q3: Can the black hull be OEM branded with custom colors?
Yes. Black is available as a custom OEM base with RAL color matching for custom orders (MOQ 10 units). We also offer carbon-fiber pattern or matte finish options for premium OEM branding.
Q4: What is the warranty coverage?
Standard warranty: 12 months on electronic components (remote, GPS module, sonar module, motor assembly). Battery warranty: 6 months. Physical damage (cracked hull from impact) is not covered. Warranty is transferable with proof of purchase.
Q5: Is the LYX-001D compatible with third-party fish finder apps?
The LYX-001D sonar operates on its own proprietary display system. It is not currently compatible with third-party fish finder apps or external displays. All sonar data is displayed on the LCD remote.
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
1× GPS+Sonar Combo Bait Boat Hull
LYX-001D main unit with GPS and sonar modules
1× 2.4GHz LCD Remote Controller
Dual-screen display for GPS and sonar data
2× 7.4V Rechargeable Battery
1800mAh Li-ion, 2-3 hours runtime each
1× Smart Charger
100-240V input with LED indicator
2× Spare Propellers
Left and right replacement propellers
1× Carry Bag
Padded transport bag with handle
1× User Manual
English operation guide with GPS and sonar instructions
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
More Products in This Category
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
HK LIANYIXIN Red GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Red
The ultimate all-in-one bait boat: GPS navigation + sonar fish finder. Scout with sonar, mark waypoints, deliver bait to exactly 3M precision. Red hull, 500M range. Shenzhen factory direct.
View Details →HK LIANYIXIN Blue GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Blue
GPS navigation + sonar intelligence in one hull. Scout new lakes with sonar, mark GPS waypoints, deliver bait with 3M precision. Blue high-visibility hull. Shenzhen factory direct.
View Details →HK LIANYIXIN Black GPS RC Bait Boat with LCD Screen
LYX-001B · Black
500M range GPS bait boat for carp fishing. Black hull — low profile, less disturbance on pressured waters. 3M GPS accuracy, 2KG dual hoppers, auto-return. Shenzhen factory direct.
View Details →Get a Free Quote Now
CE/FCC certified · Factory direct · MOQ: 1 Unit · Reply within 24 hours
LYX-001D-Black: Best For & Buyer Notes
Everything you need to know before ordering this GPS+sonar combo bait boat.
Best For
The black LYX-001D combo offers the same GPS+sonar features with a professional black hull. The top choice for carp fishing guides and premium tackle shops.
Buyer Notes
- MOQ: 1 unit (sample order supported)
- Spare battery recommended for al-day fishing
- Export packaging with foam protection
- 12-month warranty included
- CE/FCC documents available upon request
OEM / Wholesale Options
Black 001D units are popular with premium carp fishing brands in Europe. OEM service includes custom logo, retail packaging, and promotional material design. Contact our OEM team to discuss private label, custom color, and retail packaging options for your market.
