Blue GPS + Sonar Combo Bait Boat LYX-001D
Main
Angle 1
Angle 2
Feature
Scene
DetailHK LIANYIXIN Blue GPS RC Bait Boat with Sonar Fish Finder Combo
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Blue |
| MOQ | 1 Unit |
| Price | Negotiable |
| Payment Terms | T/T in Advance, Western Union, PayPal |
| Place of Origin | Shenzhen, China |
| Certification | CE / FCC / RoHS / ISO9001 |
Related Pages:
Technical Specifications
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Blue |
| Material | High-quality ABS plastic |
| Hull Size | 63.5 x 43.5 x 24 CM |
| Remote Distance | 500M |
| GPS Accuracy | 3M |
| Sonar Frequency | 125 kHz |
| Sonar Depth Range | 40M |
| Sailing Speed | 60 M/min |
| Battery Working Time | 3-3.5 Hours |
| Product Weight | 8.5 KG |
| Bait Hopper Capacity | 2 KG (Left + Right) |
| Waterproof Rating | IPX5 |
| GPS + Sonar | Dual display LCD remote |
| Auto-Return | Yes (low battery + out of range + signal loss) |
| Certification | CE / FCC / RoHS / ISO9001 |
| MOQ | 1 Unit |
| Place of Origin | Shenzhen, China |
Key Features
- ✔Dual GPS + sonar technology in one compact hull
- ✔GPS waypoint navigation with 3M accuracy
- ✔125kHz sonar fish finder with 40M depth range
- ✔Audible fish alarm when carp detected
- ✔Dual LCD display: GPS map + sonar reading simultaneously
- ✔Dual bait hopper (left + right), independently controlled
- ✔500M maximum remote control distance
- ✔Auto-return on low battery, signal loss, or manual trigger
- ✔IPX5 waterproof rating
- ✔OEM/ODM customization available
Application Scenarios
Where the LYX-001D excels — from commercial carp lakes to remote reservoirs
Multi-Session Lake Mapping Campaign
On a multi-day trip to an unfamiliar venue, dedicate the first morning to sonar scanning. Map depth contours, feature edges, and fish locations. Mark the best positions as GPS waypoints. Subsequent days of the trip use those waypoints for precision baiting.
Commercial Fishery — Fish Location + Bait Delivery
Commercial fisheries have complex fish distributions. Sail the sonar grid to locate active fish. Mark those GPS positions. Deliver bait directly to fish-holding zones rather than random pre-baiting across the swim.
Deep Lake Expedition Fishing
On deep reservoirs (15–30M), sonar reveals underwater channels, drop-offs, and gravel bars invisible from the bank. GPS marks these features for return baiting trips. The combination is the most effective tool for big-water carp fishing.
About HK LIANYIXIN
HK LIANYIXIN INDUSTRIAL CO., LIMITED is a professional manufacturer focused on miniature remote control fishing bait boats. With 10+ years of R&D and production experience, we provide stable, reliable and cost-effective products for global customers.
Our factory covers 8,000㎡ in Shenzhen, China, with a monthly capacity of 10,000+ units. All LYX series products are CE/FCC/RoHS/ISO9001 certified, exported to 50+ countries worldwide.
Frequently Asked Questions
Frequently Asked Questions
Q1: Is the dual LCD display hard to read in bright sunlight?
The LCD screens have anti-glare coating. In direct sunlight, angle the remote slightly or use a sunshade hood (available as an accessory). Night mode dims both displays automatically for low-light operation.
Q2: Can I use the sonar without GPS active?
Yes. Both functions operate independently. You can disable GPS navigation and use sonar-only mode for manual steering reconnaissance. GPS and sonar can be toggled on/off from the remote menu.
Q3: What accessories are recommended for the LYX-001D?
Recommended accessories: second battery pack (essential for all-day sessions), EVA carry case (protects dual LCD remote), boat hull cover, signal repeater for range extension beyond 500M on large open waters.
Q4: How does the LYX-001D compare to buying separate GPS and sonar boats?
The LYX-001D costs approximately 40–50% less than buying two separate boats. It also saves storage space, reduces maintenance to one hull, and eliminates the need to choose which boat to bring to a session.
Q5: Does the sonar transducer affect GPS signal reception?
No interference. The GPS antenna is located in the hull top deck, the sonar transducer is on the hull underside. Both operate on different frequencies and do not interfere with each other.
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
1× GPS+Sonar Combo Bait Boat Hull
LYX-001D main unit with GPS and sonar modules
1× 2.4GHz LCD Remote Controller
Dual-screen display for GPS and sonar data
2× 7.4V Rechargeable Battery
1800mAh Li-ion, 2-3 hours runtime each
1× Smart Charger
100-240V input with LED indicator
2× Spare Propellers
Left and right replacement propellers
1× Carry Bag
Padded transport bag with handle
1× User Manual
English operation guide with GPS and sonar instructions
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
More Products in This Category
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
HK LIANYIXIN Red GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Red
The ultimate all-in-one bait boat: GPS navigation + sonar fish finder. Scout with sonar, mark waypoints, deliver bait to exactly 3M precision. Red hull, 500M range. Shenzhen factory direct.
View Details →HK LIANYIXIN Black GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Black
GPS + sonar combo with stealth black hull. Scout with sonar, navigate with GPS, deliver with 3M precision. Low-profile hull for pressured venues. Shenzhen factory direct.
View Details →HK LIANYIXIN Blue RC Bait Boat with Sonar Fish Finder
LYX-001C · Blue
Sonar bait boat with 125kHz transducer, 40M depth range, audible fish alarm. Blue hull — high visibility scouting boat for day sessions. 500M range, 2KG dual hoppers. Shenzhen factory direct.
View Details →Get a Free Quote Now
CE/FCC certified · Factory direct · MOQ: 1 Unit · Reply within 24 hours
LYX-001D-Blue: Best For & Buyer Notes
Everything you need to know before ordering this GPS+sonar combo bait boat.
Best For
The LYX-001D blue is the full-feature professional carp fishing boat: GPS waypoints + sonar depth detection in one unit, with a high-visibility blue hull.
Buyer Notes
- MOQ: 1 unit (sample order supported)
- Spare battery recommended for all-day fishing
- Export packaging with foam protection
- 12-month warranty included
- CE/FCC documents available upon request
OEM / Wholesale Options
The 001D combo is the flagship OEM model with highest margin potential. Full private label service available for European distributors. Contact our OEM team to discuss private label, custom color, and retail packaging options for your market.
