Red GPS + Sonar Combo Bait Boat LYX-001D
Main
Angle 1
Angle 2
Feature
Scene
DetailHK LIANYIXIN Red GPS RC Bait Boat with Sonar Fish Finder Combo
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Red |
| MOQ | 1 Unit |
| Price | Negotiable |
| Payment Terms | T/T in Advance, Western Union, PayPal |
| Place of Origin | Shenzhen, China |
| Certification | CE / FCC / RoHS / ISO9001 |
Related Pages:
Technical Specifications
| Brand Name | HK LIANYIXIN |
|---|---|
| Model Number | LYX-001D |
| Color | Red |
| Material | High-quality ABS plastic |
| Hull Size | 63.5 x 43.5 x 24 CM |
| Remote Distance | 500M |
| GPS Accuracy | 3M |
| Sonar Frequency | 125 kHz |
| Sonar Depth Range | 40M |
| Sailing Speed | 60 M/min |
| Battery Working Time | 3-3.5 Hours |
| Product Weight | 8.5 KG |
| Bait Hopper Capacity | 2 KG (Left + Right) |
| Waterproof Rating | IPX5 |
| GPS + Sonar | Dual display LCD remote |
| Auto-Return | Yes (low battery + out of range + signal loss) |
| Certification | CE / FCC / RoHS / ISO9001 |
| MOQ | 1 Unit |
| Place of Origin | Shenzhen, China |
Key Features
- ✔Dual GPS + sonar technology in one compact hull
- ✔GPS waypoint navigation with 3M accuracy
- ✔125kHz sonar fish finder with 40M depth range
- ✔Audible fish alarm when carp detected
- ✔Dual LCD display: GPS map + sonar reading simultaneously
- ✔Dual bait hopper (left + right), independently controlled
- ✔500M maximum remote control distance
- ✔Auto-return on low battery, signal loss, or manual trigger
- ✔IPX5 waterproof rating
- ✔OEM/ODM customization available
Application Scenarios
Where the LYX-001D excels — from commercial carp lakes to remote reservoirs
New Venue Intelligence + Precision Baiting
Sail the LYX-001D in a slow grid, reading sonar as you go. Find a gravel bar at 350M, mark it as a GPS waypoint. Every subsequent bait run delivers within 3M of that bar. This is the most powerful workflow in modern carp bait boat fishing: scout, mark, bait, repeat.
Match Fishing Pre-Session Reconnaissance
In match fishing, swim selection is 80% of the result. Run the sonar grid before draw. Fish arches on the LCD tell you where fish are concentrated. Mark that position with GPS. After peg draw, if you get a peg near your marked position, you have pre-baited intelligence.
Long-Range Night Sessions — Full Confidence
At 3AM, operating at 450M on an unfamiliar lake: GPS waypoint mode means the boat navigates to your marked spot without visual tracking. Sonar confirms bottom composition matches your target feature. You have complete situational awareness at distance, in darkness.
About HK LIANYIXIN
HK LIANYIXIN INDUSTRIAL CO., LIMITED is a professional manufacturer focused on miniature remote control fishing bait boats. With 10+ years of R&D and production experience, we provide stable, reliable and cost-effective products for global customers.
Our factory covers 8,000㎡ in Shenzhen, China, with a monthly capacity of 10,000+ units. All LYX series products are CE/FCC/RoHS/ISO9001 certified, exported to 50+ countries worldwide.
Frequently Asked Questions
Frequently Asked Questions
Q1: Can I use GPS and sonar simultaneously on the same run?
Yes. The LYX-001D remote has two LCD panels: one displays GPS position and waypoint navigation, the other displays live sonar reading. Both operate simultaneously without interference. You can be navigating to a GPS waypoint while the sonar scans the lake bed beneath you.
Q2: How is the battery life compared to single-function models?
The sonar module draws additional power (approximately 0.3A). Runtime reduces from 4 hours (GPS-only) to 3–3.5 hours (GPS + sonar active). This is sufficient for most 6–8 hour sessions. For longer sessions, carry a spare battery.
Q3: What is the price difference between LYX-001D and the single-function models?
The LYX-001D commands a premium of approximately 25–30% over the LYX-001B (GPS-only) due to the additional sonar hardware and dual-LCD remote. For anglers who fish varied venues, this premium is justified by eliminating the need to own two boats.
Q4: Can I set multiple GPS waypoints?
Yes. The LYX-001D stores up to 10 waypoints on the GPS remote. This allows you to mark multiple features (gravel bar at 340M, silty hole at 280M, marginal shelf at 90M) and rotate baiting between them in a single session.
Q5: Is the sonar transducer protected against damage from submerged debris?
The transducer is housed in a protected recess on the hull underside, shielded from direct impact. Standard propeller and hull care practices apply. Avoid running the boat in heavily weeded areas where dense weed can wrap around the transducer stem.
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
1× GPS+Sonar Combo Bait Boat Hull
LYX-001D main unit with GPS and sonar modules
1× 2.4GHz LCD Remote Controller
Dual-screen display for GPS and sonar data
2× 7.4V Rechargeable Battery
1800mAh Li-ion, 2-3 hours runtime each
1× Smart Charger
100-240V input with LED indicator
2× Spare Propellers
Left and right replacement propellers
1× Carry Bag
Padded transport bag with handle
1× User Manual
English operation guide with GPS and sonar instructions
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
More Products in This Category
What's Included
Every LYX-001D GPS+Sonar Combo Bait Boat comes complete with these standard accessories
Quality Control & Warranty
Quality Control
- ✅ 100% function tested before shipping
- ✅ GPS accuracy verified (1-3m) for GPS models
- ✅ Sonar calibration checked for fish finder models
- ✅ IPX5 waterproof rating lab-tested
- ✅ CE / FCC / RoHS certified
- ✅ ISO9001 factory quality management
Warranty Policy
- ✅ 12-month warranty from delivery date
- ✅ Free repair for quality-related issues
- ✅ Replacement unit for major defects
- ✅ Remote technical support via WhatsApp
- ✅ Spare parts available for self-repair
- ✅ Warranty certificate included in package
Related Tutorials
Step-by-step guides for operating your LYX-001D GPS+Sonar Combo Bait Boat
Related Guides
Expert advice and buying guides from our blog
HK LIANYIXIN Blue GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Blue
GPS navigation + sonar intelligence in one hull. Scout new lakes with sonar, mark GPS waypoints, deliver bait with 3M precision. Blue high-visibility hull. Shenzhen factory direct.
View Details →HK LIANYIXIN Black GPS RC Bait Boat with Sonar Fish Finder Combo
LYX-001D · Black
GPS + sonar combo with stealth black hull. Scout with sonar, navigate with GPS, deliver with 3M precision. Low-profile hull for pressured venues. Shenzhen factory direct.
View Details →HK LIANYIXIN Red GPS RC Bait Boat with LCD Screen
LYX-001B · Red
500M range GPS bait boat for large carp lakes. 3M waypoint accuracy, 3.5–4 hour runtime, 2KG dual hoppers. Auto-return triggers on battery <20% or signal loss. Shenzhen factory direct.
View Details →Get a Free Quote Now
CE/FCC certified · Factory direct · MOQ: 1 Unit · Reply within 24 hours
LYX-001D-Red: Best For & Buyer Notes
Everything you need to know before ordering this GPS+sonar combo bait boat.
Best For
The LYX-001D red combines GPS + sonar in a high-visibility red hull. Built for professional carp anglers, fishing guides, and premium tackle distributors.
Buyer Notes
- MOQ: 1 unit (sample order supported)
- Spare battery recommended for all-day fishing
- Export packaging with foam protection
- 12-month warranty included
- CE/FCC documents available upon request
OEM / Wholesale Options
Red 001D combo models are popular with premium carp fishing brands. OEM service includes logo, color, packaging, and promotional material. Contact our OEM team to discuss private label, custom color, and retail packaging options for your market.
